Backhoe Loader 4CX
- Color (MOQ 1 set)
- Logo / branding (MOQ 1 set)
- Nameplate (MOQ 1 set)
- +1 more option
Key Attributes
Product Description
The 4CX is a full-size four-wheel-drive backhoe loader engineered for tough construction, agricultural and municipal applications. Powered by a Yuchai 4108 turbocharged diesel engine, it delivers 75 kW at 2,200 rpm with 4×4 drive and a 4F/4R hydraulic shift transmission.
Built with a heavy-duty steel frame, reinforced boom and a 190° swing angle on the rear backhoe, the 4CX handles trenching, loading, backfilling and material transport in a single machine. The 1.2 m³ front loader bucket and 0.3 m³ rear excavator bucket give operators maximum versatility on every jobsite.
Why Choose the 4CX
75 kW Turbo Diesel
Yuchai 4108 turbocharged engine — proven reliability, low fuel consumption.
28 MPa Hydraulics
High-pressure hydraulic system delivers 72 kN breakout force and 46 kN digging force.
4×4 All-Terrain
Permanent four-wheel drive with 35° gradeability tackles the roughest sites.
Air-over-Oil Brakes
Fast-response disc brakes with hand-brake parking for total safety control.
Specifications
Overall Dimensions
| Overall Dimensions | 6500 × 2500 × 3800 mm |
|---|---|
| Wheelbase | 2250 mm |
| Wheel Track | 2050 mm |
| Min. Ground Clearance | 450 mm |
| Min. Turning Radius | 4200 mm |
Performance
| System Pressure | 28 MPa |
|---|---|
| Operating Weight | 9200 / 9700 kg |
| Max Travel Speed | 38 km/h |
| Max Gradeability | 35° |
Excavator
| Max Digging Depth (telescopic) | 4000 / 5300 mm |
|---|---|
| Max Digging Reach | 5700 / 6500 mm |
| Max Lifting Height | 5800 / 6300 mm |
| Backhoe Bucket Capacity | 0.3 m³ |
| Swing Angle | 190° |
| Max Digging Force | 46 kN |
| Bucket Digging Depth | 900 mm |
Loader
| Max Dump Height | 2800 mm |
|---|---|
| Max Dump Reach | 800 mm |
| Loader Bucket Capacity | 1.2 m³ |
| Breakout Force | 72 kN |
Engine
| Engine Model | Yuchai 4108 Turbo |
|---|---|
| Engine Type | Turbocharged |
| Rated Power | 75 kW |
| Rated Speed | 2200 rpm |
| Cylinders / Bore | 4 × 108 mm |
Transmission
| Transmission | Hydraulic shift |
|---|---|
| Gears | 4F / 4R |
| Torque Converter | YJ300 |
Axle
| Axle Type | Drive axle 30 |
|---|
Tyres & Brakes
| Tyres | 16.9-28-14 |
|---|---|
| Service Brake | Air-over-oil disc |
| Parking Brake | Hand brake |
Capacities
| Fuel Tank | 150 L |
|---|---|
| Hydraulic Tank | 150 L |
Other
| Drive Type | 4×4 |
|---|---|
| Shift Type | Hydraulic variable speed |
